Just 1/2″ thick, our Compact GPS Tracker works with any vehicle. Simply connect red to constant power, black to ground, and white to the wire that is powered on when ignition is on. It’s a simple installation that takes about 30 minutes. This compact tracker can be hidden in a discrete location making it very hard to find and remove.
If you understand low-voltage electrical systems, you can probably do this yourself. If you don’t, Btracking recommends professional installation. We’d be happy to recommend a professional installer in your area.
GPS Vehicle Location Updates every 30-60 sec when moving, every 12 hours when parked
Basic Vehicle Data includes ignition on/off status, battery voltage.
No OBDII data, No Driver Behavior.
Digital Input/Outputs includes one input, one output to monitor doors, lights, or PTO
BLE Add Driver ID, tool tracking, wireless temperature and humidity sensors
Monthly Subscription from $12.95 and No Contracts
GPS Tracking and speed
Reports Location Every Minute when moving, every 6 hours when stopped (customizable)
BLE Bluetooth 4.2 interface supports sensors for Driver ID, tire pressure, temperature
Electric Vehicles Supported
Built-in triple axis accelerometer for motion and tilt (not driver behavior)
Cell Network LTE Cat M1/NB-IoT/GSM
Dimensions 3.0 in x 1.7 in x 0.5 in
Weight 2.0 oz
Internal GPS, GNSS and Cellular antennas, optional external cell antenna
Operating Voltage 12/30 v
Internal backup battery 170 mAH Li-Ion
