The Toughest, Longest Lasting Heavy Duty Asset Trackers – Protect Non-Powered and Occasionally-Powered Trailers, Containers & Machines
Trailers and containers carry valuable cargo yet are highly vulnerable to loss and damage as these assets are often left unattended for long periods of time. These assets may require constant temperature/humidity monitoring and data log reports for delivery of cold chain cargo to customers.
With Btracking you’ll know where your trailers and containers are, when they move, where they’ve been, when and where they stop and disconnect, and the status of their cargo.
For assets such as trailers and machines that are powered but may sit unpowered for periods of time, a hybrid tracker is the way to go. It reports often when on power, and when off power it has a high capacity battery capable of sending position reports 2-3 times/day for up to 5 years on a single charge.
With our powerful Pro Fleet platform, you get real time tracking, real time sensor data, and alerts on your PC or mobile device. Your drivers can get cargo data in real time on their DriverLink app which can also (optionally) track your driver’s phone location in real time.
Weatherproof I67 enclosure
Long-Life Rechargeable Battery lasts up to 5 years or 5,000 position reports on a single charge
Temperature & Humidity Monitoring Supports unlimited wireless sensors, the BLE temperature/humidity battery powered sensor, or BLE solar powered temperature sensor; and up to 6 wired temperature/humidity sensors for monitoring multiple zones simultaneously.
Disconnect/Connect/Vibration Alerts Auto alerts when and where external power is connected/disconnected, or excess vibration is detected.
Stores & Forward Stores up to 5,000 events when out of cellular coverage, then sends automatically when back in cellular coverage.
BLE supports Tool Tracking tags, sensors for temperature, humidity, pressure, load, light and more.
Easy Installation Mounts with heavy duty magnets, screws or 2-way tape.
Monthly Subscription from $19.95 and No Contracts
Cell Network 4G CATM1/NB1 with 2G Fallback. Supported bands Cat.M1 & NB1, LTE-FDD:B1/B2/B3/B4/B5/ B8/B12/ B13/B18/B19/B20/B26/B28 LTE-TDD: B39 (for Cat.M1 only) GSM850/GSM900/
Frequency Bands Quad-Band ( European 900/1800/ 2100,American 850/1900/2100
GPS GPS/GLONASS/BeiDou/Compass,Galileo, QZSS up to 1m (3ft) accuracy. GPS Technology – MTK GPS Technologies – 66 channels
RF 2.4GHz proprietary protocol, BLE (supports iBeacons, TLM and custom protocols). Range Up to 220 ft / 70m. Actual range may vary depending on RF interference, building materials, and physical obstacles Data Transmit Automatically connects to any associated Piccolo tracker and transmits every 20 seconds
Enclosure ABSPC water proof IP67 enclosure, rated UL94V-0. Shock/Vibration/Mechanical: meets or exceeds EIA standard RS-316B 3G (operating), 20G (non \operating) XYZ 3 directions. Meets SAE J1455
Dimensions 4.9” x 3.3” x 1.6” (125mm x 87mm x 41mm)
Weight 3.7oz (105g) without the batteries
Operating Conditions -22º to 176º F (-30º to 80º C). Humidity: 0 to 99% 110F (40C), non-condensing
Power Operated by Rechargeable battery – one 4.2 VDC Lithium rechargeable battery pack with a capacity of 7800mAh. When fully charged has the capacity of transmitting around 5000 GPS position. The unit has an internal fast charger. The batteries are charged via an external of the shelf standard 6-24VDC regulated power supply wall powered (110-220 AC) that plugs into the unit via a waterproof connector. Charge time is around 4-5 hours. Externally powered: runs in continuous mode acting as a real-time tracker for as long as external power is available. The internal battery will recharge for as long as external power is available. Current consumption from battery: • Standby mode: 40ma at 3V • Sleep mode: 45uA at 3V • Transmit mode: 1.8A pulse at 3V.
Buffers up to 5000 messages
Built-in triple axis accelerometer.
Operating Voltage 12/24 v
BLE Bluetooth Low Energy interface peripheral support
