btracking-BT2M1-Hardwired-Tracker-with-Driver-Behavior

BH2M1

Plug-in or Hardwired Tracker with Driver Behavior, Sensor Support, Multiple Inputs/Outputs

Features & Benefits

  • Driver Behavior, Flexible I/O’s, Driver ID Options
  • Options for Driver ID, Multiple Sensors. No OBD data. Includes 12-pin OBDII Plug-in Harness.
  • Inputs/Outputs 3 digital & 2 analog inputs, 3 digital outputs, 1-wire interface for iButton Driver ID Reader, starter immobilization, temperature sensing, doors, lights, and more
  • Fuel Monitoring LLS (Analog), LV-CAN200, ALL-CAN300, CAN-CONTROL, OBDII Dongle
    Ignition Detection Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (CAN Adapters, OBDII Dongle)
  • Internal Antenna

Highlights

Plug in or Hardwired – you can hide it in seconds – and get all the answers you need to take control of your fleet in real time.

You’ll have all the data you need to get safer drivers and a more efficient fleet. Data such as driver scorecard with speeding reports, the entire day’s stop locations, entry/exit alerts at job sites or customers, and much, much more.

Multiple Inputs/Outputs 3 digital, 2 analog inputs, 3 digital outputs, reader, starter immobilization, temperature sensing, doors, lights, and more.

Plug-in Or Hardwired 12-pin OBDII Plug-in Harness or Hardwired Harness

Driver Behavior Accelerometer for Driver Behavior monitoring. No OBDII data.

Supports Driver ID 1-wire interface supports iButton Driver ID

Sensor Support Supports multiple sensors to monitor temperature and more

Monthly Subscription from $12.95

Technical Specs

Plug-in or Hardwired Harness

GPS Tracking and Driver Behavior Speed, harsh driving, impact detection

No OBD Vehicle Data

Reports Location Every Minute when moving, every 6 hours when stopped (customizable)

BLE Bluetooth 4.2 interface supports sensors for Driver ID, tire pressure, temperature

Electric Vehicles Supported

Built-in triple axis accelerometer

Easily concealed plug-in GPS tracker with optional Y-Cable

Cell Network LTE CAT M1/ 2G GSM

Dimensions 2.5 in x 2.2 in x 0.8 in

Weight 1.9 oz

Internal GPS, GNSS and Cellular antennas

Operating Voltage 12/32 v

Internal backup battery

1 ignition input / 3 digital inputs / 2 analog inputs / 3 digit outputs / 1-wire interface
